Murphy Level Switch LS200

Liquid Level Switches with 2 in. NPT mounting are float activated to operate an electrical SPDT snap-switch (optional DPDT on some models) for alarm or shutdown of an engine or electric motor. The LS200 connects directly into the vessel wall and can be used with a FW Murphy weld collar or FW Murphy external float chamber.Designed for harsh gas compressor scrubber applications304 stainless steel float operates in 0.55 specific gravity and heavier fluidsLS200 series rated for 2000 psi (13.8 MPa) [138 bar] working pressureElectric and pneumatic models availableMore robust designAll models screw directly into the scrubber or can be mounted via external float chamberNickel plated body to provide enhanced corrosion protectionListed for cCSAus Class I, Div 1, Grps. C & D locationsCanadian Registration Number 0F01476.2Stainless steel models are available for corrosive atmospheres.Trip on rising liquid level onlySpecifications:Body: Nickel-plated; optional 316 stainless steelFloat: 304 stainless steelPressure Rating: 2000psig (13.8 MPa) [138 bar]Canadian Registration Numbers (issued by ABSA): 0F01476.2O-ring: VitonProcess Connection: 2” NPTTemperature Rating: -20° to 300°F (-29° to 149°C)Electrical: SPDT std.Wiring: 18 AWG x 36 in. (1.0 mm2 x 916 mm)
